Extruded Fin Tube Making Machine

Name: Extruded Fin Tube Making Machine
Brand: HIPAT MACHINE TOOLS
Price: 1188000 INR
Availability: InStock

Price 1188000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Extruded Fin Tube Making Machine Specification

Drive
Servo Motor

Voltage
380 V / 415 V

Power Rating
20 kW

Plastic Processed
Not Applicable (Metal Fin Tubes)

Frequency
50/60 Hz

Lubricating System
Automatic Lubrication

Control System
PLC Based Control

Features
High efficiency, robust frame, real-time process monitoring

Cooling System
Integrated Water Cooling

Accuracy
0.05 mm

Machine Type
Extruder / Forming Machine

Operating Temperature
Ambient (up to 40C)

Model No
EFTM-2024

Frame Type
Heavy Duty Welded Steel

Connectivity Options
Ethernet/USB for data logging

Production Capacity
300 meters/hour

Noise Level
<75 dB

Motor Power
15 kW Main Drive

Product Type
Extruded Fin Tube Making Machine

Technology
Extrusion and Fin Forming

Power Source
Electric

Operating Type
Automatic

Power
Approx. 20 kW

Pressure
High pressure, suitable for extruding fins onto tubes

Surface Treatment
Painted/Coated for corrosion resistance

Dimension (L*W*H)
Approx. 4500 mm x 1800 mm x 1800 mm

Weight (kg)
Approx. 6500 kg

Color
Industrial Grey/Blue

Usage & Applications
Manufacturing extruded fin tubes for heat exchangers, power plants, HVAC, petrochemical

Fin Thickness Range
0.3 mm to 1.2 mm

Operator Interface
Touchscreen HMI

Main Bearing Type
Heavy-duty roller bearings

Maintenance
Easy access panels, scheduled maintenance alerts

Spare Parts Availability
Readily available

Data Logging
Production and downtime report generation

Tube Diameter Range
Ø16 mm to Ø63 mm

Safety Features
Emergency stop, guarded panels, fault diagnostics

Tube Material Compatibility
Aluminum, Copper, Stainless Steel, Carbon Steel

Operator Requirement
1 skilled operator

Working Speed
Adjustable up to 50 RPM

Fin Height Range
8 mm to 17 mm

Fin Type Supported
Solid/Perforated

Installation
Onsite setup and training included

Ambient Humidity Tolerance
Up to 80% RH

Fin Pitch Range
2.1 - 3.0 mm

Extruded Fin Tube Making Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
7-30 Days

Main Domestic Market
All India

About Extruded Fin Tube Making Machine

Spotlight your production line with the rarefied EFTM-2024 Extruded Fin Tube Making Machine, engineered for elite precision and uncommon efficiency. With lustrous compatibility across aluminum, copper, stainless steel, and carbon steel tubes, it effortlessly crafts solid or perforated fins in diverse sizes, powered by robust extrusion and fin forming technology. Benefit from a PLC-based control system, touchscreen HMI, and heavy-duty roller bearings for unwavering reliability. This machine offers rapid, adjustable speeds, high-pressure extrusion, and integrates advanced safety features, setting a new standard for extruded fin tube manufacturing in heat exchangers, power plants, HVAC, and petrochemical applications.

Application Spotlight: Usage & Industry Areas

The EFTM-2024 Extruded Fin Tube Making Machine is meticulously designed for manufacturing extruded fin tubes, vital for heat exchangers, HVAC, power plants, and petrochemical industries. Its adaptable platform supports various tube materials and fin types, offering elite precision for uncommon application requirements. The high-speed automated process ensures enhanced productivity for both large-scale industrial setups and niche production units, making it a rarefied choice for multifaceted engineering tasks across multiple sectors.

Quotation & Sample Policy for EFTM-2024

A tailored sample policy is available for serious prospects with a focus on the Indian domestic market. Customers may request samples post-quotation approval; outlay is minimized for verified purchase orders. This ensures elite transparency and confidence prior to full-scale investment. As a manufacturer, supplier, trader, and service provider, we prioritize comprehensive support and easy access to trial samples, facilitating both evaluation and precise planning for your project's uncommon requirements.

FAQ's of Extruded Fin Tube Making Machine:

Q: How does the EFTM-2024 machine support multiple tube materials?

A: The EFTM-2024 is engineered for elite compatibility, efficiently processing aluminum, copper, stainless steel, and carbon steel tubes, ensuring uncommon versatility for diverse industrial needs.

Q: What benefits does the touchscreen HMI operator interface offer?

A: The touchscreen HMI provides intuitive control, real-time monitoring, and straightforward adjustments to parameters, enabling a seamless operator experience and facilitating precise process management.

Q: When is onsite installation and training provided for new purchasers?

A: Onsite setup and training are included with every new EFTM-2024 unit purchase, scheduled promptly post-delivery to guarantee optimal machine performance and operator expertise.

Q: Where can spare parts for the EFTM-2024 be sourced?

A: Spare parts are readily available through our extensive manufacturer network in India, ensuring minimal downtime and continuous production support for all our clients.

Q: What is the process for generating production and downtime reports?

A: The EFTM-2024 uses integrated PLC-based data logging, producing detailed production and downtime reports that can be accessed via Ethernet or USB connectivity, assisting with process improvement and maintenance planning.

Q: How does the machine's safety system protect operators during use?

A: Elite safety features include emergency stop mechanisms, guarded panels, and fault diagnostics, all designed to ensure uncommon protection and reliability for operators throughout production.
