CNC Clamp Making Machine

Name: CNC Clamp Making Machine
Brand: HIPAT MACHINE TOOLS
Price: 2588000 INR
Availability: InStock

Price 2588000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

CNC Clamp Making Machine Specification

Control System
PLC with HMI

Frequency
50 Hz

Operating Temperature
540C

Production Capacity
10001200 clamps/hr

Accuracy
0.05 mm

Cooling System
Air cooled

Drive
Servo Drive

Machine Type
Automatic Clamp Forming Machine

Frame Type
Heavy Duty Welded Steel

Lubricating System
Automatic lubrication

Voltage
415 V AC

Features
High precision, rapid tool change, energy efficient

Noise Level
<75 dB

Motor Power
5.5 kW AC motor

Connectivity Options
USB, Ethernet

Model No
CNC-CLP-108

Power Rating
7 HP

Product Type
CNC Clamp Making Machine

Technology
CNC Automation

Power Source
Electric

Operating Type
Semi Automatic

Power
5.5 kW

Pressure
Hydraulic, adjustable up to 120 bar

Surface Treatment
Powder Coated

Dimension (L*W*H)
2100 x 1400 x 1700 mm

Weight (kg)
1450 kg

Color
Industrial Grey

Usage & Applications
Manufacturing of metal clamps, sheet metal forming

Tool Carousel Capacity
12 stations

Input Material Size
Max 50 x 2 mm strip

Software Compatibility
Standard G-code, CNC Editor support

Emergency Stop
Yes, provided

Electrical Protection
Overload and short-circuit system

Cycle Time
<3 seconds per clamp

Service Support
Remote technical assistance available

WorkingSpeed
80150 cycles/min

Safety Features
Interlocked safety doors, automatic shutdown

Max Clamp Size
50 mm width

Operator Interface
Touchscreen Interface

Grease Points
Centralized greasing system

Data Storage
Onboard memory up to 32 GB

Foundation Requirement
Standard industrial floor

Main Spindle Speed
1000 RPM

CNC Clamp Making Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
7-30 Days

Main Domestic Market
All India

About CNC Clamp Making Machine

Get gilt-edged performance from the CNC Clamp Making Machine, engineered for sublime precision at an unbeatable price. This classic automatic clamp forming machine handles up to 50 mm wide material strips swiftly, producing 1000-1200 clamps per hour with a cycle time of less than 3 seconds each. Benefit from a 12-station tool carousel, powerful 5.5 kW AC motor, and advanced CNC automation. The operator enjoys a touchscreen interface, robust security features, and central lubrication system. It's a true bargain for manufacturers seeking reliability, speed, and enduring quality.

Application & Area of Use

The CNC Clamp Making Machine is used primarily for manufacturing metal clamps and sheet metal forming. Its application surface includes the production of components for automotive, construction, and general fabrication industries. The area of application spans industrial manufacturing plants, workshops, and metal processing facilities where precise and rapid clamp production is essential for operational efficiency.

Payment Terms & Export Markets

Purchase orders for the CNC Clamp Making Machine are accepted with flexible payment terms, including advanced and milestone-based payments. The machine is handed over on a standard FOB basis at major Indian ports. The rate is competitive for global buyers, making it a preferred choice in primary export markets like Asia, Europe, and the Middle East, ensuring swift delivery and secure transactions.

FAQ's of CNC Clamp Making Machine:

Q: How does the CNC Clamp Making Machine ensure high precision during clamp production?

A: The machine utilizes CNC automation with a PLC and HMI control system, achieving accuracy of 0.05 mm, alongside rapid tool change and servo drive for consistent and reliable results.

Q: What is the process for starting operation with the CNC Clamp Making Machine?

A: Operators load material strips up to 50 x 2 mm, select settings on the touchscreen interface, and initiate production. Safety interlocks and onboard memory facilitate secure and efficient operation from startup to shutdown.

Q: When should the central greasing and automatic lubrication systems be serviced?

A: Both lubricating systems are designed for minimal manual intervention but should be monitored periodically according to manufacturer guidance to maintain optimal performance and machine longevity.

Q: Where can the CNC Clamp Making Machine be installed?

A: The machine is suitable for installation on standard industrial floors in manufacturing plants, metalworking workshops, or fabrication facilities, given its heavy-duty welded steel frame and operational requirements.

Q: What are the main usage benefits of the CNC Clamp Making Machine?

A: Users benefit from gilt-edged reliability, rapid production speed, energy efficiency, and enhanced safety features, ensuring higher productivity and reduced downtime for clamp manufacturing.

Q: How does the onboard data storage and connectivity support production?

A: With 32 GB onboard memory and USB/Ethernet connectivity, operators easily store and transfer G-code programs, production data, and settings for flexible and automated workflows.
